| Brands | Ametek |
|---|---|
| Type | Tangential By Pass |
| Current | DC |
| Volt | 36 Volt |
| Watt | 539 Watt |
| Steps | 2 |
| Discharge type | Exhaust pipe |
| Height total height (mm) | 167.5 mm |
| Height turbine housing (mm) | 70 mm |
| Diameter turbine house (mm) | 144 mm |
| Cable Connectors | (-) |
| Cables On Motor | (-) |
| Diameter fan housing (mm) | (-) |
| Carbon brush no | (-) |
| Diameter exhaust pipe ID (mm) | (-) |
| Diameter exhaust pipe OD (mm) | (-) |
| Max RPM | (-) |
| Mounting holes | (-) |
| Height mounting holes (mm) | 56 mm |
| Size - Intake pipe (mm) | (-) |
| Width carbon brushes (mm) | (-) |
| OEM | 8113612M, D600 |
