| Brands | Ametek |
|---|---|
| Type | Thru Flow |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1500 Watt |
| Steps | 1 |
| Discharge type | Thru flow |
| Height total height (mm) | 124 mm |
| Height turbine housing (mm) | 44 mm |
| Diameter turbine house (mm) | 141 mm |
| Diameter fan housing (mm) | 101 mm |
| Width carbon brushes (mm) | 127.5 mm |
| Cables On Motor | Yes |
| Height mounting holes (mm) | (-) |
| Cable Connectors | Flat connector (female) |
| Diameter exhaust pipe ID (mm) | (-) |
| Mounting holes | No mounting holes |
| Diameter exhaust pipe OD (mm) | (-) |
| Max RPM | (-) |
| Carbon brush no | 3325135 |
| Size - Intake pipe (mm) | (-) |
| OEM | 6210950007, 064300130, 064300110, 064300010, 064300013, 064300015, 064300008, 064300105, 064300022, 064300088, 064300032, 6210950007 |
