| Brands | Ametek |
|---|---|
| Type | Peripheral By Pass |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1200 Watt |
| Steps | 1 |
| Discharge type | Gills |
| Height total height (mm) | 131 mm |
| Height turbine housing (mm) | 44.5 mm |
| Diameter turbine house (mm) | 130 mm |
| Diameter fan housing (mm) | 86.5 mm |
| Width carbon brushes (mm) | 116 mm |
| Cables On Motor | Yes |
| Height mounting holes (mm) | (-) |
| Cable Connectors | Flat connector (female) |
| Diameter exhaust pipe ID (mm) | (-) |
| Mounting holes | No mounting holes |
| Diameter exhaust pipe OD (mm) | (-) |
| Max RPM | (-) |
| Carbon brush no | 3320115 |
| Size - Intake pipe (mm) | (-) |
| OEM | 3023017, 6110820033, 064200027 |
