| Brands | Ametek Lamb Electric |
|---|---|
| Type | Tangential By Pass |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1250 Watt |
| Steps | 1 |
| Max RPM | 31737 |
| Discharge type | Exhaust pipe |
| Height total height (mm) | 148.5 mm |
| Height turbine housing (mm) | 25 mm |
| Diameter turbine house (mm) | 169 mm |
| Diameter fan housing (mm) | 79 mm |
| Width carbon brushes (mm) | 129 mm |
| Diameter exhaust pipe OD (mm) | 51 mm |
| Diameter exhaust pipe ID (mm) | 43.5 mm |
| Cables On Motor | Yes |
| Cable Connectors | Other type |
| Mounting holes | 3 |
| Height mounting holes (mm) | 25 mm |
| Carbon brush no | 8505969-50 |
| Size - Intake pipe (mm) | (-) |
| OEM | 122408-07 |
