| Weight | 3,02 kg |
|---|---|
| Brands | Ametek Lamb Electric |
| Type | Peripheral Q By Pass (ACUSTEK / SILENT) |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1550 Watt |
| Steps | 3 |
| Max RPM | 25620 |
| Discharge type | Gills |
| Height total height (mm) | 205 mm |
| Height turbine housing (mm) | 91.5 mm |
| Diameter turbine house (mm) | 144 mm |
| Diameter fan housing (mm) | 79 mm |
| Width carbon brushes (mm) | 124.5 mm |
| Cables On Motor | Yes |
| Cable Connectors | Flat connector (female) |
| Height mounting holes (mm) | (-) |
| Mounting holes | No mounting holes |
| Diameter exhaust pipe ID (mm) | (-) |
| Diameter exhaust pipe OD (mm) | (-) |
| Carbon brush no | 33423-12 |
| Size - Intake pipe (mm) | (-) |
| OEM | 117944-07, 066100001.02, 6110960152 |
