| Brands | Ametek Lamb Electric |
|---|---|
| Type | Tangential By Pass |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1150 Watt |
| Steps | 3 |
| Max RPM | 23930 |
| Discharge type | Exhaust pipe |
| Height total height (mm) | 198.5 mm |
| Height turbine housing (mm) | 91.5 mm |
| Diameter turbine house (mm) | 144 mm |
| Diameter fan housing (mm) | 79 mm |
| Width carbon brushes (mm) | 120.4 mm |
| Diameter exhaust pipe OD (mm) | 48 mm |
| Diameter exhaust pipe ID (mm) | 43 mm |
| Cables On Motor | Yes |
| Cable Connectors | No connectors |
| Mounting holes | 3 |
| Height mounting holes (mm) | 75.5 mm |
| Carbon brush no | 33378 |
| Size - Intake pipe (mm) | (-) |
| OEM | 116859-13, 116859-00, 6110960146, 066000007.00 |
