| Brands | Ametek |
|---|---|
| Type | Peripheral By Pass |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1200 Watt |
| Steps | 1 |
| Discharge type | Gills |
| Height total height (mm) | 136 mm |
| Height turbine housing (mm) | 45.7 mm |
| Diameter turbine house (mm) | 144 mm |
| Cable Connectors | (-) |
| Cables On Motor | (-) |
| Diameter fan housing (mm) | (-) |
| Height mounting holes (mm) | (-) |
| Diameter exhaust pipe ID (mm) | (-) |
| Diameter exhaust pipe OD (mm) | (-) |
| Max RPM | (-) |
| Mounting holes | (-) |
| Size - Intake pipe (mm) | (-) |
| Carbon brush no | 302401K (or 3325135?) |
| Width carbon brushes (mm) | (-) |
| OEM | 063700003.07, 6110950011 |
